Inductively coupled plasma is a flame-like excitation light source generated by a high frequency induction current. The sample solution is sprayed into mist, then goes into the inner tube with the working gas, passes through the core of the plasma core region, dissociated into atoms or ions and then excited to emit the characteristic spectral line. The temperature of the operating zone can reach 6000-10000 degrees Celsius. Thus the internal part of the generator must be cooled simultaneously with the industrial water chiller, to prevent tube walls from melting and ensure the normal operation of the machine.


Our client Mr. Zhong wanted to equip his ICP spectrometry generator with a water chiller and required a cooling capacity of up to 1500W, water flow rate of 6L/min and outlet pressure ＞0.06Mpa. He preferred the industrial chiller CW 5200.


The cooling capacity of the industrial water chiller, is closely related to the ambient temperature and the inlet & outlet water temperature, and it will change with the increase of temperature. Based on the heat productivity and lift of the generator, plus the performance graphs of S&A chillers, it is found that industrial chiller CW 6000(with a cooling capacity of 3000W) is more suitable. After comparing the performance graphs of CW 5200 and CW 6000, our engineer explained to Mr. Zhang that the cooling capacity of chiller CW 5200 is insufficient for the generator, but CW 6000 can meet the demand. Lastly, Mr. Zhong believed in the professional recommendation of S&A and selected a suitable water chiller.


Features of industrial chiller CW 6000:
S&A industrial chiller CW 6000 boasts constant and intelligent temperature control modes with temperature stability of ±0.5℃. The universal wheels are designed for easy installation and mobility; Clip-type installation of the dust filter on both sides is for convenient dust cleaning. It is widely applicable to UV printer, laser cutter, spindle carving and laser marking machine. With the use of environmentally-friendly refrigerant, water chiller CW-6000 features a stable cooling capacity of 3000W; It comes with multiple warning protections such as a water flow alarm, over-temperature alarms; Time-delay and over-current protection for the compressor.


With ISO, CE, RoHS and REACH approval and a 2-year warranty, S&A chiller is trustworthy. A fully equipped laboratory testing system simulates the operational environment of the chiller for continuous quality improvement and user confidence guarantee.

Teyu Water Chillers Application Cases——Closed Loop Dual Temperature Water Chiller CWFL-1000 for Cooling Laser Cutting Machine

Mr.Puspita is the senior purchasing manager of a laser company which manufactures air-driven marking machine, handheld marking machine and laser marking machine. In the communication with Mr. Puspita, we learned that his laser marking machine includes fiber laser marking machine and UV laser marking machine. For fiber laser marking machine, the cooling method is air cooling while for UV laser marking machine, the cooling method is water cooling.




According to Mr. Puspita, his company is expecting a promising future for UV laser marking machine market, so the core components need to be of high quality. For the core component -- UV laser source, they use Inngu UV laser. As for the cooling system, he chose S&A Teyu industrial water cooler CWUL-05 and abandoned the previous chiller of other brands. With 370W cooling capacity and ±0.2℃ temperature stability, industrial water cooler CWUL-05 can provide stable cooling for the UV laser marking machine.




For more information about S&A Teyu industrial water cooler CWUL-05, click https://www.chillermanual.net/high-precision-uv-laser-water-chillers-cwul-05-with-long-life-cycle_p18.html
